Special designed for cutting marble block, adopt the articulated rectilinear guides to make sure the SAW frame move straightly and stablely. (For each bearings in it are Tapered Roller Bearings, can take large axial forces). Relative big speed ratio 1: 30.

It means in the minimum normal working frequency that is 5Hz, the feed speed can slow down to 50mm/h, it's convenient for proceseing the hard marble. There are three kinds abailable each assembled 80 blades(the standard), 100 blades and120 blades.

Of the 80 blades one, it's main motor is 110KW, the lifting transduser motor is 11KW, and processing size is (L*W*H) 3200*2000*2000mm. The length of the blade is 4400mm, the thickness of each blade is 2mm~2.5mm.

Model: ZL-PJ80
Overall dimension: 12050*4200*4918
Max. Cutting dimension: 3200*2000*2100
Main motor: 110(kw)
Blade stroke: 800mm
Cycles per minute: 93
Max. Blade no: 100
Board thick: ≥ 16mm
Machineweight: 55t.
