ZD-C2600 Tyre Changer
Features
1. Mi-automatic tyre changer for commercial vehicles, trucks and coaches.
2. Lectro-hydraulic operation system.
3. Obile control unit makes operation easy.
4. Elf-centering chuck: With both automatic and manual control.
5. Im clamping spindle can turn in both directions with two different speeds.
6. Verhanging bead breaker disk mounted on tapered roller bearings.
7. Afety devices guarantee the utmost operator safety.
8. Djustable working pressure of chuck.

Technical data
Rim clamping diameter 16"-26"
Max. Wheel width 800mm
Max. Wheel diameter 1600mm
Working pressure 13Mpa
Hydraulic drive unit motor 1.5kw
Geared box motor power 2.2kw
Weight 700kg
Power supply 380v /50Hz, 3pH
Control voltage 24V, 36V
Chuck rotation speed 7.4rpm
Torque of chuck 2839Nm
Tyre dismantle force 17600N
Movable distance of slider 1200mm
Overall sizes 1970x1490x760mm
