Precision ground and supersonic frequency hardened bed ways
The spindle is supported with precision roller bearings
Headstock gears are made of high quality steel, ground and hardened
Spindle speed range 70-2000RPM
Sealed and easy operating feed box has various feeds and thread cutting functions
| Specification | ||
| Item | C0632A | C0636A |
| Max. swing over bed | 13"(330mm) | 14"(360mm) |
| Max. swing in gap | 18 3 /4"(476mm) | 19 7 /8"(506mm) |
| Max. swing over slide | 7 1 /4"(185mm) | 8 1 /2"(215mm) |
| Bed width | 7 3 /8"(187mm) | |
| Max. Length of workpiece | 30"(750mm)40"(1000mm) | |
| Spindle nose | D1-4 | |
| Spindle bore | 1 1 /2"(φ38mm) | |
| Taper of bore in spindle Morse | No.5 | |
| Spindle speed steps | 8 | |
| Spindle speed scope | 70~2000r/min | |
| Inch thread | 4~56T.P.I/32 | |
| Metric thread | 0.4~7mm/32 | |
| Diametral thread | 8~120D.P./33 | |
| Module thread | 0.2~3.5MP/27 | |
| Longitudinal feed range | 0.0032~0.1067in/r(0.082~2.71mm/r) | |
| Cross feed range | 0.00086~0.0367in/r(0.022~0.933mm/r) | |
| Max. travel of tailstock quill | 3 5 /8"(95mm) | |
| Taper hole of tailstock | No.3 | |
| Electric motor | 2HP(1.5KW)110v or 220v(1ph) 220v or 380v(3ph) | |
| Net weight/Gross weight(1000mm) | 495/595kg | |
