1. Technical Standard The performance and capacity are in compliance with the rules of High Speed Rotary Tablet Press JB20021-2004.

2. Working Condition for GZPL-620 Series High Speed Tablet Press
2.1 Granule are uniform and non-moisture, the granule content is not less than two thirds;
2.2 Granule size range: 14-60, the granule should be well fluid and plasticity;
2.3 Equipment should be installed a place, humidity is less 86%, temperature is less 35º C, in a ventilated house.
2.4 Equipment working environment should be met GMP.
2.5 Power supply: Three-phases, five wires, AC 380V, 50Hz. N and PE can not disturb each other.

4. Main Performance of GZPLS620 Series High Speed Tablet Press
4.1 Symmetrical design. Double main compression, double pre-compression, double feeder, double output, and double layer tablets.
4.2 Controlled by PLC automatically, automatic control weight of tablet system, automatic batch rejection device.
4.3 Color touch screen, automatic stop and alarm at fault, help menu, control the tablet deduster and vacuum cleaner.
4.4 Six hand wheels are used for adjusting main compression (tablet thickness), pre-compression, filling depth of two side from out to inner.
4.5 With the hydraulic support of main compression, pre-compression, the hydraulic pressure can be adjusted continuously and has the function of auto-protection and pressure overload protection.
4.6 Automatic Lubrication system, lubrication flow rate and interval can be adjusted. It is with the function of under lube alarm, lubrication pressure fault alarm and auto-stop protection, and grease lubrication system can be controlled by manual common lubrication pump.
4.7 Main motor and feeder motor are adjusted with inverter, which the speed can be regulated continuously and has the function of upper and lower limit control.
4.8 It is filled by single layer force feeder. The barrel of lower punch adopts the magnetic damping.
4.9 The tablet compartment adopts the structure of five-pole supporting frame with the window open protection and hinge sealed. The pipes and lines in tablet compartment are concealed. Tempered glass, top stainless steel cover and viewing window for upper pre-pressure roller on upper cover.
4.10 All parts in contact with drug, such as filling system, middle turret and tablet ejection device, etc. Are made of stainless steel or innocuous macromolecule material.
4.11 Main pressure overload protection.
4.12 It is equipped with the protection of electrical control system, main motor overload, feeder motor overload, upper and lower punches over tight, upper and lower camber, and the function of emergency stop, accumulated running time, parameter revised authorization and filling decreasing start.
4.13 Adjust the filling automatically to control the tablet weight and pressure. It is with the alarm function of over filling, under filling and upper and lower limit of single punch pressure value.
4.14 Hairline surface treatment.

5. Configuration of GZPLS-620 Series Double Sided High Speed Tablet Press.
5.1
Main components of electric control system adopt imported product;
The PLC is supplied by Mitsubishi;
The POD is supplied by FUJI Electric(Asia) Co., Ltd;
The Low voltage electrical parts are supplied by Siemens.
5.2 The main parts of hydraulic system are imported product.
5.3 The lubrication system is supplied by Bijur Machinery Products, Ltd...
5.4 The inverter of main motor is supplied by Sanken, and the inverter of feeder is supplied by Delta.
5.5 The main transmission adopts ZK worm at the precision grade 6;
5.6 Main bearings of transmission system adopt imported product.
5.7 Middle turret section is made from stainless steel, after the treatment of quenching, it is most suitable for producing the Chinese traditional medicine.
