XD30/XD40 Dual-drum vibratory roller

Description:
The XD30/XD40 are two light-duty tandem vibratory rollers designed for compaction operations on township roads building. Stadiums and other small-scale construction projects. They are also suited for compaction on small base courses, sub-base courses, sands and gravels. The XD 30/XD40 features a frameless structure, as compared with other XCMG roller models, allowing the machine to provide excellent compaction performance near the curb and on trenching foundations.
The XD30/40 incorporates electro-hydraulic control available to provide efficient and consistent performance coupled with increased operator comfort and reduced environmental impact. All key components and control systems, such as hydraulic pumps, motors, bearings, etc. Are internationally sourced. The roller features all-drum infinitely variable speed drive, front and rear vibrating drums, full hydraulic articulated steering, etc.

Specification:
Type  Unit  XD30  XD40
Working mass  kg  2500  4000
Axle load, front drum  kg  1300  2000
Axle load, rear drum  kg  1200  2000
Static linear load, front drum  N/cm  116  150
Static linear load, rear drum  N/cm  110  150
Speed range  Km/h  0-10  0-10
Theoretical grade ability  %  30  30
Min. Outer turning radius  mm  4000  4400
Min. Clearance  mm  200  260
Steering angle    30  30
Oscillating angle    10  10
Frequency  Hz  55  50
Nominal Amplitude  mm  0.5  0.5
Centrifugal force  kN  25  34
Vibrating Drum Diameter  mm  650  800
Vibrating drum width  mm  1100  1300
Engine Model    Deutz F2L1011F  Deutz F3L1011F
Type  Air cooling, Aspiration
Rated power@ 2600r/min  kw  20  30
Total length  mm  2450  2700
Total width  mm  1230  1452
Total height  mm  2840  2950
Fuel tank capacity  L  80  100
Water tank capacity  L  170  230
