Technical Parameter:
1) Water Inlet/Outlet: 1" F
2) Drain: 1/2"F
3) Rinse Pipe: 1.05" OD
4) base: 2-1/2" 8NPSM
5) Brine Tank Connection: 3/8" M
6) Water Capacity: 4.5t/h
7) Tank Diameter Range for Softeners: 6"-18"

Design parameters:
1) Controller model: Manual
2) Suited pressure: 0.1 - 0.6MPa
3) Suited water temperature: 5-45 degrees Centigrade

Range of Application:
1) Household purify, soften system.
2) Boiler softening water system.
3) Ro pre-treatment system.
4) Swimming pool filters equipment.
5) Ion exchange equipment.

For more Manual Softener Valve details,please contact us directly.
