RIH pneumatic solenoid valve

Two position five way
Effective Sectional Area: 16mm
CV=0.89
Port size: Inlet=outlet=1/4''
Exhaust=1/8''
Working Medium: Air(40 Micron Filtered)
Acting type: Inner guide type
Working pressure: 0.15~0.85Mpa
Max. Pressure: 1.2Mpa

Working temp.: 5~50C
Power Consumption: AC4.5VA DC: 3W
Protection Class: IP65
Wiring Form: Lead wire type or terminal type(option)
Voltage: DC12V DC24V AC110V AC220V(Option)
Max. Frequency: 5 cycle/sec.
Shortest Activate Time: 0.05Sec.
Size: 12*3*7cm per PC
