Joint size: DN10-DN65
Attended mode:
Threaded: BSP, BSPT, NPT, NPTF
Welded: DIN11850.1, DIN11850.2, DIN11850.3, SMS3008
Socket Welding

Controlling medium: Air or neutral gas
Controlling pressure range: 0.3-0.8Mpa
Control Type: Single acting(Normal open/Normal closed) , Double acting
Main Material:
Valve body: CF8M (AISI316)  or CF8 (AISI304)
Cylinder: CF8 (AISI304)
Seat seals: PTFE(Teflon)
Piston seals: FKM/NBR
Applicable medium: Water, liquid, neutral gas, water steam, slight corrosive gas and liquid
Fluid Pressure: Max. 1.6MPa (16 bar, 232Psi)
Fluid Temperature range: -10'C to +180'C
Ambient temperature: -10'C to +80'C
Viscosity: Max 600mm2/s
Installation: Any position
