Casting Material Specifications :-

• Cast Steel : ASTM A216, G.R. WCB
• S. S. 304  : ASTM A351 CF8
• S. S. 304L: ASTM A351 CF3
• S. S. 316: ASTM A351 CF8M
• S. S. 316L : ASTM A351 CF3M
• Alloy 20 : ASTM A351 CN7M

Products Inspection and Testing :-

Hydrostatic Pressure :-

• Body Test   : 10 Kg/Cm2
• Seat Test    : 10 Kg/Cm2
• (Hydrostatic pressure at room temperature using clean water.)

ElectrostaticPressure :-

• Non-destructive high-voltage test at an output voltage of 10,000 V. When electric contact is made, a visible/ audible spark or both occur at the probe if there is any defect in lining.

Visual Inspection :-

• All surfaces are free from blister, porosity or any other defect. All checks / tests are conducted before shipment.

Storage & Transport :-

• Each end of valve is protected by specially made rubber cap so that products are capable to withstand normal handling during transport.
•  All the materials are supplied with export wooden case or card box packing depending upon the weight and mode of shipment.
