Product Description
7209 B Angular Contact Ball Bearings
Single-row Angular contact ball bearings can sustain radial, axial or combined loads with the axial load being from one direction. The larger contact angle type has better axial load capacity while the smaller contact angle type has higher speed ratings. Available with polyamide, steel or bronze cages/retainers. Available in bore dimension from 10 mm to 170 mm.

Product Feature
7209 B Angular Contact Ball Bearings
Common Options:
B -- 40 degree contact angle
TVP-- Polyamide Cage
MP-- Machined Brass Cage
G-- Flush Ground

Product Specification / Models
7209 B Angular Contact Ball Bearings
(d) Bore Diameter 45.000 mm


(D) Outside Diameter 85.000 mm


(B) Width 19 mm


(C) Dynamic Load 37700 N



(Co) Static Load 28000 N



(Grease) Lubrication Speed 6700 r/min



(Oil) Lubrication Speed 9000 r/min



Mass 0.42 kg

Application
7209 B Angular Contact Ball Bearings
Electric Motor Repair
Machine Tools
metal Processing
Pulp, Paper Converting and Printing
Pump, Compressor and Oil Field
