Size:DN2”~48”

Applicable specification:
design and manufacture: API 6D, GB,DIN, JIS, BS etc..

Inspection and test: API 6D, API 598, GB, DIN etc..

Face to face: API 6D, ASME B16.10, DIN and as user’s requirement and other.

Pressure class: class 150~1500#

Valve end: RF, BW, RTJ etc as user’s required relevant specification.

Body, adapter, ball Material: carbon steel, alloy steel, stainless steel etc.(WCB, LCB, LCC,CF8, CF8M, CF3M,CF3 etc.)

seals: PTFE, VITON,PEEK, NYLON ETC.

feature: bidirectional seat or pressure relief seat, compound sealing, DBB

driven type: manual, pneumatic, electric, gas over oil etc.

application: natural gas, petroleum, chemicals, marine etc..

install: above ground, underground; horizontal, vertical etc..

option: stem extension, transition piece(pup)

temperature: meet all kinds of temperature requirement based on choosing suitable material
