we design & produce combined electro hydraulic windlass and winch, up to  500 ton, available all kinds of certificate like: CCS, ABS, LR,BV, GL, NK, DNV, KR, RINA, etc.

only capability offer the international variety certificate, insuring the quality and meet the user quality requirements.The product will be personalized to completely satisfy the technical and dimensional requirements of the application; The use of standard products guarantees an economical solution of high quality, reliability and performance.

Products name: 20 ton combined hydraulic winch and multi-drum windlass
Specification for Gypsy
40mm dia Grade 2 Chain
Rated Pull: 7 Ton x 10m/min
Max Pull: 10.2 Ton
Brake Holding: 41.2 Ton, Static
Brake: Manual Operated Band Type
Clutch: Manual Operated Jaw Type
Control: Local Control Stand
Warping End: 350mm Dia.

Specification for Drum
Capacity : 150m x 80mm dia PP
Rated Pull: 20 Ton x 9m/min @1st layer, low speed
10 Ton x 20m/min @1st layer, high speed
Brake Holding: 30 Ton, Static @1st layer
Brake: Manual Operated Band Type
Clutch: Manual Operated Jaw Type
Control: Local Control Stand
Warping End: 350mm Dia.

Specification for hydraulic power pack:
Tank Dimension: 1400mm x 1100mm x 1500mm
Oil Tank Capacity: 800Litres
Electric Motor: 2 x 30kW, IP 54, 380V, 3Ph, 50Hz
Heaterworm gear with motor for the 3-speed in line
Starter: Star-Delta for 30kW Motor
Hydraulic Pump: 71cc
Working Pressure: 180Bar ~ 230Bar
