Brand:yongwang
Model:90 deg
Butt welding 90 deg carbon steel long radius elbow ANSI standard
1, Products: 90 Deg. LR Elbow, 90 Deg. SR Elbows, 180 Deg. LR Elbow,180 Deg. SR Elbow, 45 Deg. LR Elbow, 45 Deg. SR Elbow
2, Thickness: SCH20, SGP, STD, SCH40, XS, SCH80, SCH160, XXS
3, Dimension: 1/2" to 48"
4, Material: carbon steel, alloy steel, stainless steel
5, Packing: wooden cases, wooden pallets, cartons
6, Standard:
I ASTM A234 MSS SP-75 ASME B16.9 ASME 16.28
II DIN 2605 DIN 2615 DIN 2616 DIN 2617
III JIS B2311 JIS B2312 JIS B2313
CANGZHOU YonGWANG PIPELINE MANUFACTURING CO.,LTD |
An elbow is a pipe fitting installed between two lengths of pipe or tubing to allow a change of direction, usually a 90° or 45° angle, though 22.5° elbows are also made. The ends may be machined for butt welding, threaded (usually female), or socketed, etc. When the two ends differ in size, the fitting is called a reducing elbow or reducer elbow. Elbows are categorized based on various design features as below:
|
