Sell 6 functions welding machines
2016-10-23 07:31 Views:143
Price:Negotiable
Model:HS Digital 330
Send Inquiry
6 Processes Full Digital Weding Machine 330
Features:
Adopt advanced IGBT technology, full digital control;
Combined 6 welding processes;
Easy to add and lock welding processes according to user's option;
IGBT inverter technology makes the machine more energy-saving;
For higher degrees of efficiency, lower weight and smaller dimensions;
LCD and LED display, parameters can be precise adjusted;
Synergic operation in MIG/MAG and Pulse MIG/MAG welding process;
Built-in expert datebase, widely used for various welding material and sheet thickness;
Long distance upgrading, ,monitoring ,diagnose and control;
Users can get additional value from upgrading the welding software;
Every process with 31 memory blocks easy to save and the recall the jobs. Process: MMA/TIG/Pulse TIG/Spot TIG/MIG/Pulse MIG base metals: - Aluminium
- Aluminium Alloy
- Steel
Fields of use: - Automobile and component supply industry
- Industrial plants, pipeline construction, assembly companies
- Manufacture of special vehicles and construction machinery
- Plant, container and machine construction, steel engineering
- Rail vehicle construction
- Robotic welding
- Shipbuilding / offshore
|
Technical Specification: | Rated input voltage(V) | 3-Phase AC,380V,50/60Hz | | Input voltage range (V) | 260V-460V | | Rated output capacity(A) | 315A,32.6V | | Rated open circle voltage(V) | 55V-80V | | Duty cycle | 60% | | Powers factors | 0.85 | | Efficiency | 85% | | Insulation class | H | | Dimensions L × W × H(mm) | 510x255X540 | | Weight (Kg) | 25 | | Parameter memory blocks | 31 | | Parameter for GMAW, Pulsed-GMAW welding | | Current(A) | 30-315 | | Arc force(A/ms) | 1-10 | | Voltage(V) | 10-34 | | Welding type | 0-11 | | Operation ways | 2T,4T | | Second current(A) | 30-315 | | Second voltage (V) | 10-34 | | Parameter for DC.TIG welding | | Current(A) | 3-315 | | Slope up (A/s) | 1-501 | | Slope down(A/s) | 1-501 | | Start current(A) | 40-315 | | Pilot current (A) | 3-315 | | Gas pre-flow (S) | 0.1-12 | | Gas post-flow(S) | 0.1-50 | | Operation ways | 0-6 | | Parameter for Pulsed TIG welding | | | | | Peak curren(A) | 3-315 | | Slope up (A/s) | 1-501 | | Slope down (A/s) | 1-501 | | Start current (A) | 40-315 | | Pilot current(A) | 3-315 | | Gas pre-flow (S) | 0.1-12 | | Gas post-flow(S) | 0.1-50 | | Operation ways | 0-6 | | base current(A) | 3-315 | | base time(ms) | 1-500 | | Peak time(ms) | 1-500 | | Parameter for TIG spot welding | | Ppot welding current(A) | 3-315 | | 39. gas pre-flow (S) | 0.1-12 | | Gas post-flow(S) | 0.1-50 | | Spot welding time (S) | 0.01-5 | | Slope down (A/s) | 1-501 | | Parameter for MMA welding | | | | | Current(A) | 10-315 | | Arc force(A/ms) | 0-10 | | Start current(A) | 10-315 | | Start time (s) | 0.01-1 | | Arc break adjust (V) | 20-80 |
|
