SPECIFICATIONS:
1、ELECTRICAL:
  UL APPLICATIONS:250 VOLTS AC MAX,AT2 AMPS.
  DIELETRIC WITHSTANDING VOLTAGE:500 VOLTS AC
  INSULATION RESISTANCE:100 MΩ.
  TERMINATION:RESISTANCE 20 mΩ MAX AFTER ENVIRonMENTAL TESTING

2、MECHANICAL:
  CABLE-TO-PLUG TENSILE STRENGTH:19.6 N/PCS MIN.
  DURABILITY:200 MATING CYCLES.

3、MATERIAL & FINISH
  HOUSING:POLYCARBONATE,UL94V-0 OR 94V-2.
  COLOR:TRANSPARENT OR OTHER COLOR ARE AVAILABLE.
  ConTACT BLADE:PHOSPHOR BRONZE.
  CONDUCTOR:STRANDED & SOLID WIRE,24 AWG,26 AWG.
  GOLD PLATING:3μ～50μ，ARE AVAILABLE
