2-layer Bag Making Machine: Servo Motor Driving

2016-10-23 07:50 Views:230

Price:Negotiable

Applications:

This machine is designed for bottom sealed bag or hot seal and hot cut bags. The material may be PE and/ or PP. The knife is special, one edge for PE and the or edge for PP, or one edge for bottom sealed bags and the other edge for hot seal and hot cut bags.

Features:

Mitsubishi or Panasonic servo motor, PLC and German SICK photocell. Taiwan DETAL variable frequency drive. Japanese KANEFUSA knife. The servo drive system is by our own patented system.

Technical parameters:

Model	Units	22”	26”	30”	40”	50”
Max bag width	mm	500	600	700	1000	1200
Max bag length	mm	600	700	800	1200	1500
Thickness	mm	0.01-0.20	0.01-0.20	0.01-0.20	0.01-0.20	0.01-0.20
Length tolerance	mm	0.5	0.5	0.5	0.5	0.5
Production	pcs /min	20-100	20-100	20-100	20-100	20-100
Driving motor	W	750	750	750	2200	2200
Unwind motor	W	200	200	200	200	200
Heater power	KW	2.0/2	2.4/2	3.2/2	4.0/2	5.0/2
Total power	KW	8.2	10.2	12.2	14.2	16.2
Power supply	V	AC-220	AC-220	AC-220	AC-220	AC-220
Net weight	kg	550	650	750	850	1000
Dimensions LxWxH	cm	440x105x180	440x115x180	440x125x180	440x150x220	440x175x220
Packed LxWxH	cm	220x110x180	220x130x180	220x130x180	220x150x180	220x170x180
Gross weight	kg	600	750	850	1000	1150
