Model:JK-6015
Send Inquiry
JK-6015 Two-headed Woodworking Machinery:
Usage: can be used to engrave and cut various materials.
Machine features of JK-6015 Two-headed Woodworking Machinery:
1).Particular style, competent for elaborate engraving and cutting.
2).2.2KW water-cooled spindle motor.
3).The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.
4).Be compatible with type 3, Artcut, Artcam software.
5).Memory to ensure the processing point when the blade is broken or postpone situation. Specific saving mode of different points.
Technical parameter:
| Modle | JK-6015 |
| Work dimensions | 600×1500mm |
| Body dimensions | 800×1700×1200mm |
| Z-zxis working area | >100mm |
| Max.Feeding height | 100mm or bigger |
| Cut thickness of material | ≤30mm |
| Max.Speed | 6000mm/min |
| Working speed | 0-4000mm/min |
| Mechanical precision | 0.01mm |
| Softwar | type3,Artcut,Artcam software |
| Max.Power consumption | 1800W |
| Power source | AC 220V/50Hz |
| Driver type | stepper motor |
| Spindle | 1500W variable speed,water-cooled |
| Spindle speed | 0-24,000rpm |
| Blade diameter | 1-6mm |
| Control system | NCSTUDIO |
