Model:TY-200
Send Inquiry
| Item | Unit | 200g |
| Screw Diameter | mm | 42 |
| Screw Speed | r/min | 10-230 |
| Theoretical Shot Volume | cm³ | 200 |
| Injection Rate | g/s | 150 |
| Injection Weight | g/s | 200 |
| Injection Pressure | mpa | 150 |
| Clamping Model | — | Double Toggle |
| Ejector Force/Stroke | mm | 60 |
| Clamping Force | kn | 1000 |
| Max. Mould Platen Stroke | mm | 280 |
| Mould Thickness | mm | 380 |
| Space Between Tie Bars | mm | 420x290 |
| Mould Size | mm | 580x450 |
| Heating Power | kw | 6.3 |
| Motor Power | kw | 11 |
| Machine Weight | T | 2 |
| Machine Size | M | 1.58X1.0X2.9 |
