Model:SJ*2 Series
Send Inquiry
SJ2 Series Double Head Film Blowing Machine
Usage
This machine set is used for blowing LDPE and HDPE plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry, gamedet industry and textile industry, etc.
Main technical variable
Model | SJ*2-65 | SJ*2-70 | SJ*2-75 |
Screw diameter | 65mm | 70mm | 75mm |
Screw ratio | 1: 28 | 1: 28 | 1: 28 |
Screw speed | 10-110r/min | 10-110r/min | 10-110r/min |
Max output | 50kg/h | 70 kg/h | 90 kg/h |
Max.folding width of film | 550mm*2 | 650mm*2 | 750mm*2 |
Single-side thickness of film | 0.006-0.10mm | 0.006-0.10mm | 0.006-0.10mm |
Power of main motor | 18.5-22kw | 22-30kw | 37kw |
Total power | 40kw | 55kw | 70kw |
Weight of machine | 3000kg | 3800kg | 4500kg |
Overall dimension(m) | 4.8*2.2*3.8 | 5*2.4*4 | 5.2*2.6*4.2 |
