Two Pieces Washing Down Closetool Squatting WC Pan Toilets Seats

Specification of FB-CII2

Toilet Bowl Size:650*360*395mm
Water Inlet:64mm
Sewage Draining Exit Outsider Diameter:105mm,Inner Diameter:86mm
Tank connecting hole Diameter:16mm,Center to Center:158mm
Seat Cover installing hole Diameter:16mm,Center to Center:150mm
Seat Cover size:440*360mm
Anchor Bolt Installing Hole Diameter:10mm

Top Flush Button Tank Size:390*200*360mm
Flush Button Hole:40mm
Side Water Inlet hole:22mm
Water outlet:64mm
Tank connecting hole Diameter:16mm,Center to Center:158mm
Whole size of Bowl and Top Flush Button Tank:675*360*755mm
S-trap, Distance from Sewage Exit to Wall:200mm
