Traditional Wired Alarm System with two-way communication CX-7206/7208
2016-10-23 08:31  Views:88
Price:Negotiable
Model:CX-7206/7208
Send Inquiry

Delivery Time:whthin 7 days after receving payment or deposit
Certification:CE FCC ROHS

Wired alarm system>Traditional Wired Alarm System with two-way communication
Model:CX-7206/7208

Traditional Wired Alarm System with two-way communication>Brief Description

1.dopt bran new 16 bit MCU.
2.Dual Serial Port
3.Support two-way communication
4.support GSM &TCP/IP protocol, network alarm?

Traditional Wired Alarm System with two-way communication>Features

New Function:
* Dual Serial Ports, access to wired and wireless keyboard.
* Support two-way communication, enable work with 8 dual-way wried keypad, 8 dual-way wireless keypad, 8 dual-way remote.
* support GSM and TCP/IP protocol, network alarm settings.
* dopt bran new 16 bit MCU.
Basic Function:
* roll menu introduction without manual
* 6, 8 total programmable zones. 6, 8 user passwords
* Can be controlled by remote CMS
* 8 groups users code could be used temporarily.
* 2 central station telephones, events reported b every telephone could be set dependently.
* 24 hours zone type
* Auto reporting faulty connection with central station
* Remote programming software.
* Support 4+2, FSK, Contact ID, support GSM, Internet dual-net communication.

Traditional Wired Alarm System with two-way communication>Parameter:

Product ModelCX-7206/7208?
Operation temperatureAlarm panel: -30°C~+50°C
LCD keypad: 0°C~+50°C
LED keypad: -10°C~+50°C
Humidity75%
Input voltage14V AC, 2A
Backup battery12V DC, up to 7.2 Ah
Current consumptionAlarm panel 44mA
LCD keypad 15mA
Other keypad 20mA
Output voltage750mA, 13.8V DC
