ISO9001, ISO14001

CE,UL, ROHS

Pitch:2.5mm,2.54mm,3.5mm,3.81mm,3.96mm,5.0mm,5.08mm,6.35mm,7.5mm,7.62mm,9.5mm,10.16mm,15mm,19mm

Poles:2p-24p

Screw:M2/M2.5/M3/M4/M5, Galvanized  Steel  or Brass

Wire cage: Galvanized  Steel or Ni Plated Brass

Pin Header: Tin Plated Brass.

Housing:PA66.UL94V-0/PBT.UL94V-0

Rated Voltage:250V,300V,650V,700V,750V,1000V

Rated Current:4A,8A,10A,12A,15A,24A,25A,30A,32A,57A,65A,80A,125A

Withstanding Voltage:AC1250V,AC1500V,AC2000V,AC2500V,AC3000V,AC3500V,AC8000V/1min

Wire Range:3-24AWG
