Furniture Steel Hinge:Two way slide on hinge,Concealed Hinge,steel hinge

Products Specifications:
Material:steel cup nickel plated
Opening angle:110 degree
Diameter of hinge cup:35mm
Depth of hinge cup:11.3mm
Hole pitch:45mm/48mm
Door size:3mm-7mm
For door thickness:14mm-24mm
Cup fixed wood screw 4mm/Euro-screws 6.3mm/ Dowels 10mm

Product Features:
1.Cycle test 50,000 times opening and closing guaranteed
2.Lifetime above 8 years
3.Antirust protection layer
4.With functions of height and side adjustments
5.Full overlay,half overlay,inset available
6.Mounting plates of various designs in different heights available.
7.Self-tapping screw and Euro screw available
8.Weight:Around 26g-75g,can meet other requirements.
9.Good quality with factory price.
10.Selfl-manufactured and direct selling.
11.High reputation,good credit standing and on time delivery.
12.Good after-sales service.

we have wide choice of different types of cup and mounting plate fixings.We can do the products according to your requests.Please ask us for details.
