NO.1 sheet,bed sheet,towel,table cloth,clothes industry washer and dryer machine
2016-10-23 09:19  Views:35
Price:Negotiable
Model:XGQ
Send Inquiry

NO.1 sheet,bed sheet,towel,table cloth,clothes industry washing and dehydrating machine series





Liquid crystal display, operation interface of dialogue between human and machines, being able to realize intelligence system operation automatically pouring water to pre-washing, rinsing, bleaching, and cleaning, with 30types of washing programs and available, of which 5types frequently used programs inside what adapt yourself to changing circumstances
Unique structure of suspension and shake-proof, without making a base for shaking ,improves greatly the stability of the machines.
Adopting imported system of frequency conversion assures the maximum speed and maximum rotary speed. The separation factor improves greatly, so it not only assures the washing quality, but also improves the drying efficiency.
imported axletree and framework oil seal assures the liability of rotary precision and airproof, and reduces the rate of troubles
Large stainless gate with gate control system from Germany improves greatly the safety during using.
Heating gates of steam and hot water are prepared.

        This series of washing machine of main use for washing textile about cotton ,fibre,chemical fibre,have advantage of large washing capacity,good effect washing, shake small, Noise Lower and fuul Automatic operation,be suitable for laundering and dyeing industry about guesthouse,hotel,hospital,army,academy ect.

Specifications

Model

XGQ-15F

XGQ-25F

XGQ-50F

XGQ-80F

XGQ-100F

Washing Capacity

15KG

25kg

50kg

80kg

100kg

Laundry cylinder size

Φ625×480mm

Φ800×500mm

Φ970×650mm

Φ1200×700mm

Φ1200×850mm

Power

1.5kw

2.2kw

5.5kw

11kw

11kw

Voltage

220/380v

220/380v

380v

380v

380v

Laundry Speed

40r/min

40r/min

35r/min

33r/min

32r/min

Dehydration rate

750r/min

750r/min

750r/min

700r/min

700r/min

Total Weight

0.45T

0.75T

1.4T

3.2T

3.35T

Size

1000×900×1400mm

1100×1050×1600mm

1600×1455×1850mm

1750×1650×2050mm

1850×1650×2050mm
