Model:SJYQ
Main point:
1.Capacity:300kg
2.Lifting height:6m-12m
3.Table size:Min1650*750mm
the specification of the product:
Model | Lifting height(m) | Capacity(kg) | Table size(mm) | Total dimension(mm) | Mating power(kw) |
SJYQ0.3-6 | 6 | 300 | 1650*750 | 3150*1300*2100 | 2.2 |
SJYQ0.3-8 | 8 | 300 | 1650*800 | 3150*1400*2200 | 2.2 |
SJYQ0.3-10 | 10 | 300 | 2100*1220 | 3430*1800*2300 | 2.2 |
SJYQ0.3-12 | 12 | 300 | 2550*1500 | 4150*2100*2850 | 2.2 |
We can also design goods according to your requirements.Then please tell us the following information:Capacity,Lifting height,Table size.
Introduction:
1. The lifting height of the scissor lift is 6m, 8m,10m ,12m and so on.
2. The capacity of scissor lift is 300kg.
3. The scissor lift is easy to control. It could be control on the ground or on the table. Remote control.
Power driven:
1.Power of the scissor lift could be electronic or diesel or manual. And the lifting drive of the lift is hydraulic.
2.The platform makes use of external power to do traction, the use of three-phase power or diesel-powered, mobile conveniently.
Scope of working:
It is applicable to long-distance operations. Mainly used in petroleum, electricity, urban construction and other industries of Posts and Telecommunications field high above the ground.
