Model:FLY-AD
Send Inquiry
Features:
- Wall-mounted typeUniversal inputOptional output connectorOverload and short circuit protection Operating temperature: 0 to +40°COperating humidity: 5 to 90% relative humidity (non-condensing)
Technical parameter
Input voltage: 100 to 264V AC
Input frequency range: 47 to 63Hz
Input current: 0.8A at 100V AC
Efficiency: 75% at rated voltage
DC output voltage: 11.4 to 12.6V
DC output rated current: 0 to 2A
DC output power: 24W
Ripple and noise: ≤120mV at full road with 20MHz bandwidth
Turn-on delay time: ≤3s (110V AC and full load)
Dimensions: 93.5 x 47 x 33mm
Safety certification: CE, UL, FCC, C-TICK, PSE, and CB
