Model-F
Full overlay F011, Half overlay F012, Inset F010

Slide-on Concealed Hinge, Two-action

Material: steel with nicked plating

Max door opening angle: 105°

Cup diameter: 35mm

Cup drilling depth: 11.3mm

Hole pitch: 48mm

Cup thickness: 0.8mm

Hinge arm thickness: 1.0mm/1.2mm

Mounting plate thickness: 1.0mm

With spring, Self-closing

(F011: Accepts clip-on buffering device to hinge arm)

Mounting Plates of 4 designs available

3 dimensional adjustments: side, depth and height

Variable side adjustment +2 mm / -2mm

Variable depth adjustment +2 mm / -2 mm
Height adjustment via mounting plate + 2 mm / -2 mm
Guarantee at least 50,000 times opening and closing
Pass the 48-hour salt spray test
