Ring hammer crusher for crushing all kinds of hard and abrasive weak materials. The material compressive strength does not exceed of 100Mpa, Moisture content is less than 15%. Broken material is coal, salt, chalk, gypsum, brick, limestone etc. It also can broke fiber structuremore flexibility and toughness of the broken wood, paper, waste of asbestos cement, recycling of asbestos fibers and so on...Besides, Hammer crusher can be used not only in broken production line, sand production line system, but also can replace the cone crusher in the mineral processing production line.
Ring hammer crusher Working Principle :
The main working parts of ring hammer crusher is the rotor with a hammer (or hammer), rotor is composed of spindle, disk, pin and hammer. The motor drive the rotor with high-speed rotation in the broken cavity, materials from the up mouth feeder into the machine, it is crushed by high-speed movement of the hammer blow's impact, shear, grinding. Under the rotor, there is a screening plate, the crushed material whose size is smaller than the sieve can come out through the sieve, the other material whose size is bigger than the sieve will still be combated and grinded by the hammer, finally through the plate out.
PCH series ring hammer crusher owns the impact rotor with a special ring hammer. When the material enters into the crusher, it can be crushed by the ring hammer which is revolved by the high-speed motor, at the same time the material obtained the kinetic energy and rushed at the impact plate receiving the second crushing process, then falls on the screen sieve and be cut, extruded, and grinded by the ring hammer. At last the material up to the standard can be discharged by the machine. Uncrushable material enters into the metal collector and should be eliminated regularly
PCH Series Ring Hammer Crusher Features :
1. The ring hammer crusher is designed with a simple structure, large crushing ratio and high production efficiency.
2. It is highly efficient and energy saving, and causes low noise and little dust.
3. The space between grid sections can be adjusted to change discharging granularity in line with clients' needs.
4. The alloy hammerhead has excellent corrosion resistance and its service life is 1.5~2 times that of normal high manganese steel.
