Specifications:
Model: ZEUEE-BOTOBO01
Capacity: 40-50 PCS/Min
Power: AC 220V 50Hz 1200W
Pressure: 0.4-0.6 Kgf
Weight: 380 KG
Size: 2400(L)*1200(W)*1800(H) MM
Usage: Apply to the BOTOBO connector for automatic assembly.

Features:
I. The accessories of the machine adopted FESTO/SMC original pneumatic component, Japan THK precision slide rail, precision mold is grinding of S136, cutter parts is made of SKD11 material. Mitsubishi PLC touch screen operation interface.

2. This machine can load plastic automaticlly, and the terminals are attached on the machine in disk-shaped. This machine has the following functions as automatically loading materials, inserting terminals, cutting terminals, automatically bending,shaping, revising, detecting faults, and packing.  All the procedures are performed automatically.

3. With automatic alarming system reporting irregular issues and giving the corresponding solutions in the form of message. It can also induct the incoming materials automatically and point out the lack of materials, predict and record the capacity.
