Type CSK is a sprag type freewheel integrated into a 62 series ball bearing (except sizes 8 and 40). It is bearing supported, delivered grease lubricated and protected against dust of more than 0,3mm. The use of additional "nylos" type seals is recommended especially when the working temperature exceeds 50°C.

Oil bath lubrication is also possible.

All the CSK versions are equipped with "Formchromed" sprags. The process increases several times the overrunning life time.

Torque transmission is ensured by a press fit assembly into a rigid outer housing with N6 tolerance, and onto a shaft with n6 tolerance. The initial bearing radial clearance is set at C5, and is red-uced if using the press fit as specified.

Please contact us when either the ambient or the operating temperature is not in the range +5°C to +60°C.
