Treatment Principle of Vacuum body Shaping system V8

1. Infrared laser lowers skin impedance by heating skin and RF energy penetrates deeply into connective tissue.
2. The synergistic combination of infrared laser and conducted RF energy increases the oxygen intracellular diffusion by heating skin.
3. The technology that vacuum folds skin makes RF energy penetrate a specific folded skin, significantly improving effect and safety, even for the upper eyelid area treatment.
4. Vacuum plus specially-designed rollers manipulate leads even RF penetration (5-15mm). Meanwhile, vacuum and roller mechanical tissue manipulation nips and stretch fibrillar connective tissue, effectively break down subcutaneous fat as well as extruded capillary vessel, increase lymphatic drainage, promote metabolism and reduce or shrink the size of the actual fat chamber, thereby greatly improving body shaping effect.

Applications of Vacuum body Shaping system V8

Our body contouring system is suitable for body shaping, body circumference reduction, cellulite reduction, skin tightening, wrinkle removal, skin surface smooth, massage, and eyelid area treatment.

 Advantages of Vacuum body Shaping system V8

1. Body shaping system V8 features revolutionary combination of bipolar radio frequency, near-infrared laser, vacuum and pulse mechanical tissue manipulation.
2. The safety and effectiveness of V8 technology have been demonstrated in body contouring and wrinkle removal on any parts of human body.


Technical Specifications of Vacuum body Shaping system V8

LED Screen: a) Main screen: 8" TFT Chromatic Touch Screen
                        b) Screen of applicator: Screen of applicator 1: 2.4"
Screen of applicator 2: 1.9"
Vacuum: Pulse mode
                a) Absolute pressure:80kpa-10kpa (60.8cmHg-7.6cmHg)
                b) Relative pressure: 20kpa-90kpa (15.2cmHg-68.4cmHg)
Laser: 940nm
Applicator tips: 4
Net weight: 55kg
RF frequency: 1 MHz
Rollers speed: 0-36rpm
Laser power: Max 20 W
Wireless IC card management
Rollers working mode: 1 type
Safety Testing Mode: Real-time online
Energy Density of RF: Max 60J/ c m3
Rated input voltage: AC230±10%, 50Hz±1Hz/
AC110V±10%,60Hz±1Hz (optional)
Physical dimensions: 625mm*525mm*1070mm
Treatment area of handpiece: 4mm*7mm/ 8mm*25mm/30mm*50mm/40mm*60mm

Thanks for your interest to our body shaping system V8-shape,here please kindly find the pictures of our machine, if you want to know more about our machines or other further information,please feel free to contact me!

                    The operating menu of V8-shape

                       The control part of the handpieces

                                       No. 1 Handpiece
