Model:QT10-15
QT10-15 Full automatic block making machine
1.ISO9001/CE/SGS
2.Special design
3.Mitsubishi PLC,Siemens motor,Omron limited switch
QT10-15 Main technical parameters
Dimension of host machine | 3500×2220×2850mm | Host machine power | 45.38KW |
Moulding area | 1025×810mm | Vibration force | 100KN |
Moulding period | 15-25S | Mixer model | JS750 |
The size of the pallet | 1350×900×30mm | General water Consumption | 12T/every day |
Weight of the host machine | 14T |
|
|
Voltage | 380V |
|
|
Theoretical workshop area : 200m2 , need about 7-8 workers .the office , curing area and stacking area to arrange according your fact status.
Production capacity
Size(LxWxH) | Pcs/Mould | Pcs/ Hr | Pcs/ 8 Hr |
400x100X200 | 20 | 3000-3600 | 24000-28800 |
400x150X200 | 14 | 2100-2520 | 16800-20160 |
400x200X200 | 10 | 1500-1800 | 12000-14400 |
400x250X200 | 8 | 1200 | 9600 |
Paver:200x100X60 | 35 | 5250 | 42000 |
Paver:200x165X60 | 20 | 3000 | 24000 |
We have the right to improve some according the workmanship and technology developin fact
