Brief Introduction:

--Our company supplies customized gypsum block molding machine, with the SIZES as follow:
666*500*60,666*500*80,666*500*90,666*500*100,666*500*120,666*500*150,333*500*100,333*500*120mm

--One machine can make hollow or solid, or both solid and hollow, with one size.

--Our gypsum block machine is a hydraulic type of molding machine, includes mixing part, molding part, ejection part, hydraulic part, electrical system and operating system.


Main Technical Parameter:

1) Block Size:                   666(length)*500(width)*60~150(thickness)mm
2) Capacity:                     10pieces/mold, 250m2/10hours
3) Molding Period:          7—8molds/hour
4) Rated Pressure:        15MPa
5) Max Pressure:            31.5MPa
6) Installed Power:        15KW

Production Line:

1) Parts of Equipments: mixer, molding machine, overhead travelling crane, hydraulic Station, Trolley;
2) Labour in one line: 3-4 people/day shift;
3) Capacity: 100, 000 m2/year;
4) Advantage: low energy consumption, cover small area, easy and simple to handle, high output
