Model:YZC12

Working Weight :12500Kg

Front Wheel Distributed Weight:6200Kg

Rear Wheel Distributed Weight: 6300Kg

Static Linear Pressure:290/295N/CM

Vehicle frame Form: Fork Feet

Crab Walking Distance: ±170MM

Water Tank Volume: 480/430L

Fuel Tank Volume:215L

Hydraulic Oil Tank Volume:107L

Vibration Amplitude(High/Low):0.75L/0.35L

Vibration Frequency(High/Low):40Hz/50Hz

Exciting Force: ≥105KN / ≥78.5KN

Traveling Speed(First/Second Speed):0-7Km/h / 0-13.5Km/h

Turning Diameter(Inside/Outside):8190MM / 12460MM

Climbing Ability:40%

Steering Angle: ±34°

Vibratory Wheel Diameter:1350MM

Vibratory Wheel Width:2135MM

Vibratory Wheel Rim Thickness:20MM

Vibratory Wheel Horizontal Oscillating Angle: ±8°

Sprinkling Form: Pressure

Wheel base:3480MM

Total Length:5370MM

Total Width:2326MM

Total Height:3160MM

Min. Ground Clearance: 400MM

Diesel Engine Model: BF4M1013

Diesel Engine Power:88Kw

Diesel Engine Rotating Speed:2300R/Min
