Ring Hammer Crusher overview:
The PCH ring hammer crusher is used for crushing various fragile materials which are moderately hard and have weak corrosivity, such as gangue, coal, salt, chalk, gypsum, tile, limestone, coke, red sandstone, slag, shale, etc. Both dry crushing and wet crushing are available. The ring hammer crusher can also be applied for crushing fiber structure, scrap wood which has strong elasticity and toughness, waste paper, broken asbestos cement, etc.

Ring Hammer Crusher working principle:

PCH ring hammer crusher is a type of impact crusher with ring hammer head. The hammer not only revolves around the rotor in the driving of motor, but also revolves around the hammer shaft. When the materials are put into the cavity, it was crushed firstly by the high-speed ring hammer, then the material get the energy from the ring hammer and rush at the impact plate in a high speed, it falls down to the grid plate after the secondary broken, be sheared ,extruded, grinded and be further crushed. the final product which size is less than the gap of grid hole flow down the machine, and the bigger size material will be stricken continually, and discharge the machine through the grid plate finally.

Ring Hammer Crusher application:

The ring hammer crusher is used for crushing moderately hard and fragile materials in the mining, cement, coal, metallurgy, building materials, and road industries, etc. Not only can the ring hammer crusher be applied in crushing production line and sand making production line, but it also replaces the cone crusher in beneficiation production line.

Ring Hammer Crusher Features:

1. The ring hammer crusher is designed with a simple structure, large crushing ratio and high production efficiency.

2. It is highly efficient and energy saving, and causes low noise and little dust.

3. The space between grid sections can be adjusted to change discharging granularity in line with clients' needs.

4. The alloy crusher hammer has excellent corrosion resistance and its service life is 1.5~2 times that of normal high manganese steel.
