Building lifter widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
The lifter has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity
SC series of building lifter main technical parameters
| Parameter | SC100 | SC100/ 100 | SCD200A | SCD200/200A | SC200 | SC200/200 | SC200P | SC200/200P |
| Rated loading capacity (kg) | 1000 | 1000/1000 | 2000 | 2000/2000 | 2000 | 2000/2000 | 2000 | 2000/2000 |
| Rated lifting speed (m/min) | 36 | 36 | 36 | 36 | 36 | 36 | 0-56 | 0-56 |
| Rated passenger number | 12 | 12/12 | 24 | 24/24 | 24 | 24/24 | 24 | 24/24 |
| Engine power | 2*11 | 2*2*11 | 2*11 | 2*2*11 | 3*11 | 2*3*11 | 3*18.5 | 2*3*18.5 |
Cage | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 | 3*1.3 *2.5 |
| Cage weight (kg) | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 | 1400 |
| Mast section weight (kg) | 163 | 163 | 163 | 163 | 163 | 163 | 163 | 163 |
| Mast section dimension (mm) | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 | 650*650 *1508 |
| Counterbalance weight (kg) | 1200 | 1200/1200 | ||||||
| Hanger rated lifting capacity (kg) | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Bottom outline dimension (mm) | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 | 3100*4200 |
We can also supply construction elevators whose dimension of mast section is 800*800*1508mm. There are also inclined and curvilinear styles.
