JAC Single-axial multi-functional sprinkler adopted the qualified Sort2 leading imported and domestic chassis, applied in sorts road for sprinkling, spraying, temperature reduction and dust dunghill removing, moreover, available for roads conserving, Landscaping, fire fighting and drinking water transportation etc.
MAIN SPEC.:
ITEM MODEL&SPEC. MANURACTURER
SPECIAL VEHICLE Single-axial multi-functional sprinkler Hubei Cheng Longwei Special Purpose Vehicle Co., Ltd
CHASSIS JAC HFC1124K1R1 Anhui Jianghuai Automobile (JAC)
ENGINE YC6J190-20 Yuchai Group Co., Ltd (CYD)

CHASSIS TECHNIQUE PARAMETERS:
ITEM MODEL&SPEC. ITEM MODEL&SPEC.
Drive System 4*2 Exhaustion Standard EU2CN2Emission(ml)/ Power(kw) 6494/140 Tyre & Spare Tyre Spec. 8.25-20,9.00-20
Gross /Rated / Kerb Mass(kg) 12060/5000/6865 No. of  Leaf  Springs 9/9+7
Dimension(L*W*H)(mm) 9075×2400×2855 F/R Suspension(mm) 1535/2450
Wheelbase/Axis No.(mm) 5000 Approach /Departure Angle(°) 19/15
F/R- Gearcase   F/R Truck(mm) 1900/1800
Driver Cab Inline  Clutch
Steering-Gears power-assisted steering Brake System Bleeding Brake
Gearbox CA6T1386th gear, Auto hand-gear

VEHICLE MODIFCATION TECHNIQUE INFORMATION
ITEM MODEL&SPEC. ITEM MODEL&SPEC.
Cubage(m3) 7-8 Sprinkle Height(m) ≥15
Material Carbon Steel, Stainless Steel, Aluminum-alloy, AluminumPlastic Shoot Range(m) ≥30
Shape Circumference, Ellipse, Round Max Vertical Suction ≥7
Dimension(L*W*H)(mm) 6860×2380×1620 Pressure(Sprinkling/Spouting) 250-450KPa
Pump( Optional) Sprinkling, Fire Engine Watering 0.2-2(l/)
Manufacturer Qualification Measure up (CN standard) Outlet Pressure 90m
Painting metallic Paint Abstraction Time Consume <5min
Spare Parts & Accessories Maintenance ManualServices Stations ListIntroductionTools Flowing 60 m3/h
Introduction The vehicle modified on JAC chassis, advantaged with its high strength rigidity chassis, hoisting pump, flank design of water adding and pumping, easy operating, large aperture is convenient of affusion, provide for a safe and comfortable condition of controlling, withal durable in use.
Products feature The vehicle sprinkler system consisted of front irrigating (spouting), rear sprinkling, side showering works, elevated showering.  Provided for rear foot platform equipped with high power adjustable spouting gun that rain formed of straight ,down pouring , moderate ,drizzle, spraying and also would used for crop-dusting. Parameters as: vertical section>7 M, Sprinkling range >14 M, Shooting >28 M. While such vehicle could be used for high pressure flushing, fire fighting, motive pump station etc.
