Model:JH36-400D
Send Inquiry
A).Features of J36 series close two-point single-action press machine:
1.Both JH36-250D and JH36-400D are general mechanical press machine.They can complete blanking,bending,drawing shallow,correction and other stamping technology,and are quite suitable for producing auto,electric appliance.
2.The press body adopts combined struture, and the drive system uses 3-stage drive.
B).The main parameters of close two-point single-action press machine:
| MAIN TECHNICAL SPECIFICATIONS FOR STRAIGHT SIDE TWO- POINT SINGLE ACTION MECHANICAL PRESS | |||
| Model & Specificatons | JH36-250D | JH36-400D | |
| Nominal capacity (kN) | 2500 | 4000 | |
| Nominal pressure stoke (mm) | 11 | 13 | |
| Stroke length (mm) | 400 | 400 | |
| Strokes per minute (spm) | 17 | 16 | |
| Max. die height (mm) | 600 | 900 | |
| Die height adjustment (mm) | 250 | 400 | |
| Distance between gibs (mm) | 2560 | 2620 | |
| Area of slide bottom(FBxRL)(mm) | 2560x1250 | 1400x2790 | |
| Bolster surface(RBxRLxTH)(mm) | 1290x2770x160 | 1600x2780x200 | |
| Style of bolster | fixed table | fixed table | |
