1.SPLIT BODY TYPE, STAINLESS STEEL FLANGED BALL VALVE, FULL PORT
2.Flange Dimension : ANSI B16.5 Class 150/300
3.Face to Face Dimensions : ANSI B16.10
4.Material : CF8M(DIN 1.4408), CF8(DIN 1.4308), WCB(DIN 1.0619)

• Split Body to Allow Inspection and Maintenance on All Internal Parts.
• Anti-Static Device, Blow-out Proof Stem, Solid Ball., Lever-Operator.
• Fire Safe Design, with Virgin(Pure) Teflon Seats.
• Pressure Test Standard Acc. To ANSI B16.34
• Investment Casting Body/Caps (1/2"-6"), Sand Casting Body/Caps 8" to 10"
• Design for ISO-5211 Mounting Pad

OPTIONS :

* Special Alloy and Hollow Ball Available Upon request.
* Graphite (Grapfoil) Gasket/Stempacking Available Upon Request.
* Gear Operator, Actuator Operator (Option)
