Di 342 mm Tolerance: +0, 5
Da 486 mm Tolerance: -0, 5
Da ZT 484 mm Valid for bearings with centring (suffix ZT)
Centring lengths (see dimension drawing)
Tolerance: -IT8
Di 415, 5 mm Tolerance: +0, 5
Da 412, 5 mm Tolerance: -0, 5
Di ZT 344 mm Valid for bearings with centring (suffix ZT)
Centring lengths (T, t) (see dimension drawing)
Tolerance: +IT8

H 56 mm
La 460 mm
Li 368 mm
Na 24 Number of fixing holes in outer ring
Ni 24 Number of fixing holes in inner ring
M 29 kg Mass
Fr per 99100 N Maximum permissible radial load against friction lock
Ca 169000 N Basic dynamic load rating, axial
C0a 560000 N Basic static load rating, axial
Cr 111000 N Basic dynamic load rating, radial
C0r 248000 N Basic static load rating, radial
4 taper type lubrication nipples, DIN 71412-A S8x1, spaced uniformly on circumference
