Brand:FAG
Model:FAG NNU4922-S-K-M-SP
NNU design FAG double row Cylindrical roller bearings, with a very low cross sectional height, provide a higher degree of stiffness than bearings in the NN 30 series.
Description of FAG bearings NNU4922-S-K-M-SP
Non-locating bearing, double row, with tapered bore (taper 1:12), separable, with cage, reduced radial internal clearance, restricted tolerances
Cross reference: SKF NNU 4922 B/SPW33
ID: 110 mm
OD: 150 mm
Width: 40 mm
Weight; 2.01 kg
Basic dynamic load rating: 132 kN
Basic static load rating: 270 kN
Fatigue load limit: 42.5 kN
Limiting speed for grease lub.: 5000 rpm
Limiting speed for oil lub.: 6000 rpm
Part FAG double row Cylindrical roller bearings catalogue
Part No | d mm | D mm | B mm |
NNU4920-S-K-M-SP | 100 | 140 | 40 |
NNU4921-S-K-M-SP | 105 | 145 | 40 |
NNU4922-S-K-M-SP | 110 | 150 | 40 |
NNU4924-S-K-M-SP | 120 | 165 | 45 |
NNU4926-S-K-M-SP | 130 | 180 | 50 |
NNU4928-S-K-M-SP | 140 | 190 | 50 |
NNU4930-S-K-M-SP | 150 | 210 | 60 |
NNU4932-S-K-M-SP | 160 | 220 | 60 |
NNU4934-S-K-M-SP | 170 | 230 | 60 |
NNU4936-S-K-M-SP | 180 | 250 | 69 |
NNU4938-S-K-M-SP | 190 | 260 | 69 |
NNU4940-S-K-M-SP | 200 | 280 | 80 |
NNU4944-S-K-M-SP | 220 | 300 | 80 |
NNU4948-S-K-M-SP | 240 | 320 | 80 |
NNU4952-S-K-M-SP | 260 | 360 | 100 |
NNU4956-S-K-M-SP | 280 | 380 | 100 |
NNU4960-S-K-M-SP | 300 | 420 | 118 |
NNU4964-S-K-M-SP | 320 | 440 | 118 |
NNU4968-S-K-M-SP | 340 | 460 | 118 |
NNU4972-S-K-M-SP | 360 | 480 | 118 |
NNU4976-S-K-M-SP | 380 | 520 | 140 |
NNU4980-S-K-M-SP | 400 | 540 | 140 |
NNU4984-S-K-M-SP | 420 | 560 | 140 |
NNU4988-S-K-M-SP | 440 | 600 | 160 |
NNU4992-S-K-M-SP | 460 | 620 | 160 |
NNU4996-S-K-M-SP | 480 | 650 | 170 |
NNU49/500-S-K-M-SP | 500 | 670 | 170 |
FAG double row Cylindrical roller bearings NNU4922-S-K-M-SP are mainly used inmachine tools. The taper enables more accurate adjustment of clearance or preload during installation
