Model:ZT-L12E-OT
Send Inquiry
- 1. Ambient temperature -40C...+60C
- 2. Viscosity 12 ...800 mm2/s
- 3. Fluid temperature -15C...+80C
- 4. Filtration 10 to NAS 1638
- 5. Max operating pressure 315 bar
- 6. Back pressure 50 bar
- 7. Nominal flow 50 l/min
- 8. Leakage(A,B-T) 15cm3/min at 120bar
- 9. Actuating force < 200 N
- 10. Modification/ Spools with 1 to 6
- Package Size: 14.0 * 21.0 * 12.0 ( cm )
- Gross Weight/Package: 4.5 ( kg )
- Manually or mechanically controlled hydraulic directional control valve ZT12 is designed for distribution and control of work flow between generator (pump) and executive mechanisms (cylinder, hydro-motor, etc.). It is manufactured with 1 to6 plungers, with parallel or serial action, with common or individual back valve for each plunger, with or without safety valve.
- ZT12 is a mono-bloc distributor. Its body is made of cast iron. Plungers are made of carburized steel with hard chrome plating.
