Trunnion Ball Valve



Size: NPS2"~48"



Rating: Class150~2500



Material: WCB, LCB, LCC, WC6, WC9, CF8, CF8M, CF3, CF3M, 4A, 5A A105, LF2, F11, F22, F304, F316, F304L, F316L, F51, F53



Design and manufacture standards: API 6D, BS 5351, API 608, ASME B16.34



Face to face standards: ASME B16.10, API 6D, DIN 3202,



Connections standards: ASME B16.5, ASME B16.25, ASME B16.47, DIN 2501, BS 4504



Test standards: API 598, AP16D, BS 6755, ISO 5208



Constructions:

Two-piece body, Three-piece body

Double Block & Bleed

Bi-direction sealing

Seat and stem sealant injections

Anti-static device

Blow-out Proof Stem

Fire safe as per API607

Full bore, Reduced bore



Operation: Lever, Gear, Electrical actuator, Pneumatic actuator
