Sanitary butterfly valve, Butterfly Valve, valve
Max pressure: 1.0 Mpa (10bar )
Specification: DN15-200 and 0.5"~8"
Standard: ISO, DIN, 3A, SMS, IDF, RJT, etc
Material: AISI304, AISI316L
Connection: Welded, male, clamped, flanged
Driver: Manual, pneumatic, electric
Manual oparation: Pulling handle, multi-position handle
Pneumatic device: Normally closed, normally opened, opened and closed by two air flues separately
Electric drive: (DC)12V, 24V, 36V (AC)220V, 380V
Seal ring: Silicon rubber, EPDM or FPM
Application: Dairy, beverage, food, beer, pharmaceutical, biotechnology, cosmetic etc.
