Galaxy series BB ball valves featuring forged steel split body side entry design. Specially designed for high pressure service so as to replace traditional turnnion mounted design to save cost. Upon special request, this series of valve can also designed to have Cryogenic or High temperature service.

Design Standard:
Basic Design:   BS 5351
Test:                API 598, BS 6755, API 607
Products Range:
Size:                       1/2" ~ 4"
Rating:                    ANSI 600lb ~ 2500lb
Body Materials:        Forged carbon steel, Stainless steel
Trim:                       A105+ENP, 13Cr, F304, F316
Operation:               Handwheel, Gear, Pneumatic operator
Design Feature:                   Application:
Full port or Reduce port           Refinery
Fire safe certified                    Chemical
Blowout-proof stem                 Petrochemical
Anti-static                              Power plant
Low emission control              Pharmaceutical
ISO 5211 top flange
Optional locking device
