Brand:KOYO
Model:6000
Send Inquiry
| ITEM CODE | ID | OD | WIDTH | CHAMFER | LOADING(KN) | BALL | MAX RUN SPEED | WEIGHT | |||
| Dynamic | Static | No. | Size | Grease | Oil | KG | |||||
| Cr | Cor | mm | r/min | r/min | |||||||
| 6000 | 10 | 26 | 8 | 0.3 | 4.55 | 1.95 | 7 | 4.763 | 29000 | 34000 | 0.019 |
| 6001 | 12 | 28 | 8 | 0.3 | 5.1 | 2.39 | 8 | 4.763 | 26000 | 30000 | 0.021 |
| 6002 | 15 | 32 | 9 | 0.3 | 5.6 | 2.84 | 9 | 4.763 | 22000 | 26000 | 0.035 |
| 6003 | 17 | 35 | 10 | 0.3 | 6.8 | 3.35 | 10 | 4.763 | 20000 | 24000 | 0.04 |
| 6004 | 20 | 42 | 12 | 0.6 | 9.4 | 5.05 | 9 | 6.35 | 18000 | 21000 | 0.068 |
| 6005 | 25 | 47 | 12 | 0.6 | 10.1 | 5.85 | 10 | 6.35 | 15000 | 18000 | 0.079 |
| 6006 | 30 | 55 | 13 | 1 | 13.2 | 8.3 | 11 | 7.144 | 13000 | 15000 | 0.113 |
| 6007 | 35 | 62 | 14 | 1 | 16 | 10.3 | 11 | 7.938 | 12000 | 14000 | 0.149 |
| 6008 | 40 | 68 | 15 | 1 | 16.8 | 11.5 | 12 | 7.938 | 10000 | 12000 | 0.185 |
| 6009 | 45 | 75 | 16 | 1 | 21 | 15.1 | 12 | 8.731 | 9200 | 11000 | 0.231 |
