Thrust Ball Bearings

2016-10-23 18:32 Views:192

Price:Negotiable
Model:01111

Product information:

this type of bearings is separable,which can only carry axial load.the single direction bearings of them can only carry axial load in one direction,while the doucle can carry alternating axial load in either direction.Before using they have to be preloaded.The thrust ball bearings are used in lathe centers,automobile cluches,reducers and so on.The double direction angular contact thrust ball bearigs are suitable for machine tool spindles,while the single are support ball screws.

Specification	Boundarydimentions(mm)	Approx.Mass	Specification	Boundarydimentions(mm)	Approx.Mass
	d	D	B	(kg)		d	D	B	(kg)
51100	10	24	9	0.019	51209	45	73	20	0.31
51101	12	26	9	0.021	51210	50	78	22	0.378
51102	15	28	9	0.023	51211	55	90	25	0.599
51103	17	30	9	0.025	51212	60	95	26	0.672
51104	20	35	10	0.037	51213	65	100	27	0.756
51105	25	42	11	0.056	51214	70	105	27	0.793
51106	30	47	11	0.064	51215	75	110	27	0.845
51107	35	52	12	0.081	51216	80	115	28	0.931
51108	40	60	13	0.012	51217	85	125	31	1.22
51109	45	65	14	0.143	51218	90	135	35	1.69
51110	50	70	14	0.153	51220	100	150	38	2.25
51111	55	75	16	0.227	51222	110	160	38	2.42
51112	60	85	17	0.281	51224	120	170	39	2.69
51113	65	90	18	0.324	51226	130	190	45	3.95
51114	70	95	18	0.346	51228	140	200	46	4.3
51115	75	100	19	0.389	51305	25	52	18	0.169
51116	80	105	19	0.417	51306	30	60	21	0.267
51117	85	110	19	0.44	51307	35	68	24	0.386
51118	90	120	22	0.646	51308	40	78	26	0.536
51120
