Guangxing supply v wire water well screens,which are extensively applied deep wells  .They are combined with v wire (wedge wire ) and support rod .

Technical Specifications:

Pipe Size (Inch)
NB Standards 2",3",4",6",8",10",12"

Slot (mm)
Standards; 0.25-0.50-0.75-1.00-1.50-2.00-3.00
Customized Slots - Just Ask

Materials of Construction
AISI 304 & 316 Grade Stainless Steel, Low Carbon Steel, Galvanized Steel.

Screen Lengths (Metres)
Standard Lengths; 2.90 & 3 Metres or 5.80 & 6 Metres
Customized Lengths - Just Ask

Different Screen End Fittings Available
Plain or Threaded Ends as required.

Mechanical Design
Water Well Screens are designed for depths of 100 Mt, 200 Mt, 350Mt, and 600 Mt.

Advantage

1 A continuous slot opening which significantly increases the available open area, thus providing greater access to the water bearing zone.

2 A Vshaped profile wire which avoids clogging and ensures an uninterrupted flow.

3 A uniform and efficient well development due to the continuous slot opening.

4 Ladder-like wire welded screens have a strong structure and high open area, as well as accurate slot dimension.

5 Ladder-like wire welded screens have the features of easy backwashing, last long, safety and reliability as well as low comprehensive cost.
