Brand:TIMKEN
Model:32204
Type | Boundary Dimensions(mm) | Basic Load Rating (kN) | Weight | |||
d | D | T | Cr. | Cor. | (Kg) | |
32204 | 20 | 47 | 19.25 | 32.5 | 34.8 | 0.156 |
32205 | 25 | 52 | 19.25 | 39.5 | 43.5 | 0.186 |
32206 | 30 | 62 | 21.25 | 50.7 | 57.9 | 0.292 |
32207 | 35 | 72 | 24.25 | 69.6 | 82.4 | 0.453 |
32208 | 40 | 80 | 24.75 | 77.7 | 90.8 | 0.554 |
32209 | 45 | 85 | 24.75 | 84.2 | 104 | 0.583 |
32210 | 50 | 90 | 24.75 | 85 | 105 | 0.646 |
32211 | 55 | 100 | 26.75 | 107 | 133 | 0.863 |
32212 | 60 | 110 | 29.75 | 132 | 167 | 1.17 |
32213 | 65 | 120 | 32.75 | 157 | 203 | 1.58 |
32214 | 70 | 125 | 33.25 | 169 | 225 | 1.664 |
32215 | 75 | 130 | 33.25 | 174 | 234 | 1.71 |
32216 | 80 | 140 | 35.25 | 203 | 271 | 2.14 |
32217 | 85 | 150 | 38.5 | 232 | 315 | 2.69 |
32218 | 90 | 160 | 42.5 | 263 | 362 | 3.44 |
32219 | 95 | 170 | 45.5 | 311 | 439 | 4.26 |
32220 | 100 | 180 | 49 | 347 | 495 | 5.21 |
4) Features:
Tapered roller bearing mains bear with radial primarily, the axial union load. Bearing outer ring rolling bearing capacity depends on the way Angle, the greater the carrying capacity of the larger Angle. This type of bearings is bearing separation, according to the bearing of the roller column number into a single, double row and four row circular cone roller bearings. The single row circular cone roller bearing clearance to users in the installation to adjust; Double row and four row circular cone roller bearings clearance has set up a file in the products based on user requirements given, don’t need to adjust by the users.
5) Application:
Tapered Roller Bearings are used for Cars, Trucks, Railways, Ships, Mines, metals, Petrochemicals, Power, Agricultural machinery, Industrial machinery and so on
2) 32204 Tapered Roller Bearing:
Product | 32204 tapered roller bearing |
Old Code | 7504E |
Brand | TIMKEN, OEM service, neutral brand |
Dimensions | 20x47x19.25mm |
Material | Bearing steel GCr15 |
Precision | P0, P6, P4, P5 |
Tolerance | ABEC1, ABEC3, ABEC5 |
Hardness | HRC58-64 |
Vibration | V1, V2, V3 |
Noise Grade | Z1V1, Z2V2, Z3V3, Z4V4 |
Payment term | T/T, LC |
Delivery time | 7-45 days after confirm the order |
Product advantage | 1.Assembly |
2.Windage test | |
3.Cleaning | |
4.Rotary test | |
5.Greasing and gland | |
6.Noise inspection | |
7.Appearance inspection | |
8.Rust prevention | |
9.Product packaging as customers' requirement |
