HPI Baja 5B (GC15240)
2016-10-24 01:32  Views:211
Price:Negotiable
Send Inquiry

HPI's new giant 2WD Baja 5B buggy will take RC Cars to a new dimension!

The Baja 5B is a rear wheel drive 1/5th scale off-road buggy that is nearly 32" in length! Its design is revolutionary for large scale RC Cars following the style of classic Baja buggies with long suspension arms for great ground clearance and large suspension travel. The big size allows the Baja 5B to go where smaller buggies can't and makes the Baja 5B's driving experience as close as you can get to the real thing.

The Baja 5B is big, but coming as a "Ready To Run" car, and powered by standard petrol it can't be easier to get ready for action. Everything is included in the kit - 1. Preassembled Baja 5B chassis, 2. Prepainted Baja body shell, 3. Preinstalled high quality FM radio gear with built in fail safe, 6V receiverpack and charger. 4. Preinstalled massive 23cc petrol engine providing plenty of power. All you need to do is fill up with standard petrol and some oil, and off you go!

HPI Baja 5B Specifications:
Chassis
Overall Length: 817mm
Height: 255mm 1G (280mm with 0G)
Width: Front 460mm / Rear 480mm
Tire Track: Front 395mm / Rear 400mm
Wheelbase: 570mm
Ride height: 76mm
Suspension travel: Front 95mm / Rear 100mm
Weight: 21.3lb
Camber: Adjustable front with shims rear with screw
Front caster: Adjustable with shim 22 / 25.5* / 29 degrees (* stock)
Toe-in: Adjustable front with tie rod rear with shims 2 / 3* / 4 degree each side (* stock)
Aircraft aluminum 6061 T6 monocoque chassis
Double wishbone suspension with adjustable roll center F/R
Twin plate ventilated disk brake
Drive system: HD metal gears with sealed gear box (8.382: 1 gear ratio)
Diff: Viscous Torque control with 4 pinion gears sealed diff case with silicone oil
Shock absorber: 5 position adjustable dampening and fully adjustable coil over spring
Wheel type: 3 pcs with high impact nylon material
Engine

2 cycle piston valve gasoline engine
Cooling system: Air cooled
Displacement: 23cc
Maximum output: 2.4ps
Fuel: Pre-mixed fuel, 25 (Gasoline): 1 (High grade 2 cycle engine oil)
Starter: Recoil Starter
Radio

FM radio system with fail safe system
Steering servo: Hi torque water resistant 25kg. Cm with Speed 0.16sec/60 degree
Throttle servo: Hi torque water resistant 6kg. Cm with Speed 0.16sec/60 degree
Receiver battery: 6V rechargeable NiCad battery
